Variant
with inner tube
14051701017 FLEXA HG-CU-K Hollow braided tube tinned copper wire Range of application 12.0 mm - 22.0 mm smooth inside
Please select variant:
| Tiered price | |
|---|---|
| from 1 metre | €14.60 |
| from 150 metre | €13.78 |
| from 300 metre | €12.94 |
| from 600 metre | €12.11 |
from €14.60
Business notice:
Price per metre. Sold only in PU of 100 metres. Do you need lower quantities? Please contact us. This is a special purchase and cannot be cancelled or returned. The exact delivery time will be confirmed after receipt of order.
Discount group:
XY
14051701017 FLEXA HG-CU-K Hollow braided tube tinned copper wire Range of application 12.0 mm - 22.0 mm smooth inside:
| Type: | Hollow braided tube tinned copper wire |
| Design: | HG-CU-K |
| Series: | Special tube |
| Nominal width: | 15.0 mm |
| Diameter Range of application: | 12.0 mm - 22.0 mm |
| Temperature range: | Range of application: -25°C to 90°C short: 100°C |
| Material: | Hollow braid: tinned copper wire Basic structure/Interior structure: Polyvinyl chloride (PVC) Braiding: Copper tin plated |
| Colour: | Colour shade: silver |
| Approvals / Standards: | -VDE EN/IEC 61386-23 |
| Tube assembly: | - All-plastic tube, plus braiding of round braided wires with double crossing in the various braiding angles - smooth inside - around - tinned copper wire braid |
| Features: | - Axially upsettable in a certain ratio, up to 2 times the diameter depending on the braid construction. - Coverage greater than 85 percent. - Easy retraction of cables. - Apply tightly by stretching. - Protection from hot chips. - Good shielding properties, shielding factor up to 30 MHz according to EN 50289-1-6 up to 80 dB. - Round braid for cable bundling. |
| Area of application: | -Automation -Plant engineering -Mechanical Engineering -Electronics -Rail vehicles -Shipbuilding -Vehicle construction |
| Matching data: | Cable conduits |
14051701017 FLEXA HG-CU-K Hollow braided tube tinned copper wire Range of application 12.0 mm - 22.0 mm smooth inside:
| Manufacturer: | FLEXA |
| Manufacturer designation: | 14051701017 |
| Manufacturer Short description: | HG-CU-K Tressage creux, tinned copper NW |
| Aliases: | - 1 4051 701 017 - 1.4051.701.017 - 1-4051-701-017 - 4051701017 - 4051 701 017 - 4051.701.017 - 4051-701-017 |
| Customs tariff number: | 83079000 |
| EAN: | 4025113211736 |
| Classifications: | - ECLASS 5.1.4 27140903 - ECLASS 7.1 27430303 |
The photographs and graphics are not to scale and are not detailed images of the respective products.
Manufacturer or responsible person for the product in: FLEXA GmbH + Co KG, Darmstädter Straße 184, 63456 Hanau-Steinheim, Germany
