Variant
PUR jacket
1696963/PUR/17 Phoenix Contact M12 Sensor cable PUR 4-pole Socket straight drag chain capable A-Coding, Length 17.0 metres black grey RAL 7021, Cable Outer diameter 4.2 mm
✓ By the piece & by the metre ex stock ✓ sensor lines up to 40m excess length available ex stock ✓ No packaging units, no minimum order value
Please select variant:
| Tiered price | |
|---|---|
| from 1 piece | €70.64 |
| from 10 piece | €63.57 |
| from 20 piece | €56.51 |
| from 40 piece | €49.44 |
| from 80 piece | €42.38 |
from €70.64
Discount group:
S2
1696963/PUR/17 Phoenix Contact M12 Sensor cable PUR 4-pole Socket straight drag chain capable A-Coding, Length 17.0 metres black grey RAL 7021, Cable Outer diameter 4.2 mm:
| Type: | Sensor cable PUR |
| Series: | drag chain capable |
| Design: | straight |
| Type: | Screw lock |
| Number of poles: | 4 |
| Coding: | A |
| Confection Page 1: | Type: bare cable end |
| Confection Page 2: | Thread: M12 Type: Socket Design: straight |
| Cable details: | Conductor cross-section mm²: 0.34 mm² Conductor cross-section AWG: AWG22 Outer diameter: 4.2 mm Cable length: 17.0 metres |
| Minimum bending radius: | moves: 10.0x Outer diameter fixed relocated: 5.0x Outer diameter |
| Rated voltage: | 250V |
| Rated current: | 2A |
| Pollution level: | 3 |
| Overvoltage category: | II |
| Contact resistance: | <=5.0mOhm |
| Temperature range: | moves: -25°C to 80°C fixed relocated: -40°C to 80°C |
| Mating cycles: | >=100 |
| Protection class: | IP65 / IP67 / IP68 |
| Range of application: | Energy guiding chains: Yes shielded: No with LED: No |
| Material: | Insulating body: Polyurethane (PUR) Contact Pin: Bronze (CuSn) Contact Socket: Bronze (CuSn) Contact surface: Nickel (Ni)/Gold (Au) Coat: Polyurethane (PUR) Core insulation: Polypropylene (PP) Seal: Nitrile rubber (NBR) Knurled screw: Zinc die-cast nickel-plated |
| Colour: | Outer sheath: black grey RAL 7021 |
| Approvals / Standards: | Fire behaviour according to UL: HB according to UL94 |
| Fire behaviour: | -halogen-free -flame-retardant |
| Environment: | -hydrolysis-resistant -microbe-resistant |
| Chemical: | -chemically resistant -silicon-free |
| Oil resistant: | -oil-resistant |
1696963/PUR/17 Phoenix Contact M12 Sensor cable PUR 4-pole Socket straight drag chain capable A-Coding, Length 17.0 metres black grey RAL 7021, Cable Outer diameter 4.2 mm:
| Manufacturer: | Phoenix Contact |
| Manufacturer designation: | 1696963/PUR/17 |
| Manufacturer Short description: | Sensor/actuator cable, 4-pin, variable cable type, free cable end, to straight M12 socket, coding: A, cable length: 17 metres |
| Aliases: | - 1696963.PUR.17 - 1696963-PUR-17 |
| Customs tariff number: | 85444290 |
| EAN: | 4069948248970 |
| Classifications: | - ECLASS 5.1.4 27250107 - ECLASS 7.1 27249090 |
The photographs and graphics are not to scale and are not detailed images of the respective products.
Manufacturer or responsible person for the product in: PHOENIX CONTACT Deutschland GmbH, Flachsmarktstraße 8, 32825 Blomberg, Germany
